Product Introduction
Overview
Figure 3.1 Robot overview
The main components of the robot system include:
 Nova robot: six-axis robot arm, main moving parts.
 CCBOX: core computing and electrical components.
 Emergency stop switch: connected to the control cabinet to realize the emergency stop
function.
 Wireless receiver: plugged into the CCBOX, so that the operating terminal can be
connected to and control the robot via WiFi.
In addition, the system includes an operating terminal (tablet or PC) for installing the robot
control software.
Figure 3.2 Operation terminal
