Robot arm
Composition
Nova series robot arm includes 6 rotating motion joints, and two connecting rods (upper arm
and forearm), as shown in Figure 3.3. The robot arm is equipped with a hand-guiding button and an
indicator light at its end, and an aerial plug on its end flange side.
Figure 3.3 Nova robot arm
End button and indicator lights
Nova series robot arm is equipped with a button and an indicator light, as shown in Figure 3.4.
Figure 3.4 End button and indicator light
