Electrical Features
CCBOX interface
Overview
The interfaces of the CCBOX are shown in Figure 6.1.
Figure 6.1 CCBOX interfaces
Robot interface
It is used to connect the robot arm for powering the robot arm and communicating with the
robot arm.
Power interface
It is used to connect the external power supply for powering the CCBOX.
