Installation mode Any angle Any angle
Cable length
①
3m (118.1 in) 3m (118.1 in)
Material
acrylonitrile butadiene
styrene plastic
acrylonitrile butadiene styrene
plastic
① cable length between the robot arm and the controller.
Appendix B CCBOX technical specifications
Product CCBOX
Size 200*120*55 mm (7.9*4.7*2.2 in)
Weight 1.3 kg (2.9 lb)
Input power 30~60V DC
IO power 24V, Max 2A, Max 0.5A for each channel
IO interface DI 8 inputs (PNP or NPN)
DO 8 outputs (PNP or NPN)
AI 2 inputs, voltage mode, 0~10V
AO 2 outputs, voltage mode, 0~10V
Communicat
ion interface
LAN 2
USB 2
RS485 1
Environment
temperature
0~50℃
Environment humidity ≤95%, no condensation
Remote power on/off Support
IP rating IP20
Cooling mode Passive heat loss
Teaching mode PC (Windows), APP (iOS/Android)
