A.Type
TC/AM
Torque control / angle monitoring
Torque values (TARGET) are critical in judging fastening (OK/NG) while angle values are
sub-values.
AC/TM
Angle control / torque monitoring
Angle values (TARGET) are critical in judging fastening (OK/NG) while torque values are
sub-values.
B.Target torque / Max. torque
TC/AM
Target torque
Sets target torque values in TC/AM
AC/TM
Max. torque
Sets maximum torque tolerance in reaching target angle in AC/TM.
If the torque exceeds the maximum torque in reaching the target angle,
an error occurs right away.
C.Torque limit / Min. torque
TC/AM
Torque limit
Sets OK range in percentage based on target torque
E.g.). In the case of 100.00 kgf.cm of target torque and 10% torque limit,
‘90.00-110.00 kgf.cm’ is OK while other areas are NG.
AC/TM
Min. torque
Sets minimum torque tolerance in reaching target torque
E.g.). In the case of 1,000 target angle and 1.00 kgf.cm of minimum
torque, torque should be at its minimum level or higher even at a
temporary situation while reaching the target angle.
D.Target angle
TC/AM
Target angle
Unused
AC/TM
Target angle
Sets the target angle
E.Min angle
Able to apply the minimum angle value in judging OK/NG.
Resulted in ‘NG’ if the angle is lower than the minimum level even after the target torque is reached in TC/AM
mode.
F.Max angle
Able to apply the maximum angle value in judging OK/NG.
Resulted in ‘NG’ if the angle is greater than the maximum level even after the target torque is reached in
TC/AM mode.
