DOM Roq® Smart Lock
Remove Old Cylinder
DOM Roq® Fig. 07: Remove Old Cylinder
Attention!
Only remove the cylinder when the door is open and secured against closing.
1. Insert the key into the cylinder (A) from the inside.
2. Remove the forend screw (fixing screw of the cylinder). (B)
3. Remove the existing cylinder (C) by turning the key slightly.
(Starting from the basic position approx. 30° to the right or left).
4. As soon as the locking lug of the cylinder is in the basic position (flush, 6 o'clock), you
can remove the cylinder with the key.
