DOM Roq® Smart Lock
Mounting
Proceed in the order described and observe the notes and illustrations.
Attention! Damage due to the use of unsuitable tools.
Only use the "tool" described in the mounting procedures for mounting. DOM
accepts no liability for damage caused by the use of unsuitable tools.
Note! For assembly, use a soft support (e.g. foam) on which you can store the
individual parts during mounting. By using the support, you can ensure that you
do not lose any parts when you attach the components.
Attention!
Always mount the DOMRoq® on the inside of the door.
For doors that open outwards, please contact your DOM specialist dealer.
The mounting instruction describes general mounting procedures that apply to all attachment
types. Thus, the basic handling of the mounting assemblies, the base plate, the motor unit
and the attachment of the base plate to the respective add-on element are described first.
This is followed by a description of the mounting procedure, which only applies to the particu-
lar mounting situation.
