DOM Roq® Round / Oval Rosette and Spanish Rosette Without Screw Connection Through Inner
Rosette
50
DOM Roq® Smart Lock
DOM Roq® Fig. 45: Round / Oval Rosette and Spanish Rosette Without Screw Connection Through Inner Rosette
16. Cut the foam piece according to dimension h and the shape (pay attention to the
printed pattern lines) of the trim. (H)
17. Remove the protective film from the foam part and stick the foam part accurately onto
the base plate. (I)
Attention!
It may not be possible to remove the foam board from the base plate afterwards
without damaging it!
