DoorKing 80 Series Owner's Manual

1835-065-D-5-17
9
Bottom View
Side View
Front View
Recess Box
Threaded Stud
1.2.1 Surface Mount Recess Kit Dimensions and Installation
Surface mount units can be recessed into a
wall or pilaster by using the optional surface
mount recess kit (P/N 1803-150). This allows
for a recessed telephone entry system to
have a lighted keypad (except for the 1833)
which the flush mount units DO NOT have.
The recess box gets installed in the wall. Use
appropriate hardware (not included) to
secure the box in the wall. Run all necessary
conduit (not included) to the recess box.
Slide the enclosure in the recess box and
secure it with the hardware included in the
kit. Be sure the unit is mounted securely and
is not subject to vibration from closing doors
or gates.
9”
11.25”
6”
6”
2.625”
2.625”
.4”
.4”
3.2”
1”
8.5”
13.25”
2.625”
1.125”
2.5”
25” Dia. Mounting Hole
1.375” Dia.
15.25”
13.25”
13.375”
3.625”
Mounting
Holes
.25” Dia.
Knock-outs
Surface Mount
Enclosure
Plastic Spacer
Locknut
Recess
Box
Mounting Screws (Not supplied)
Mount In a Surface
Wall
A
Z
CA
L
L
7
7
8
8
9
9
4
4
5
5
6
6
1
1
2
2
3
3
0
0
O
P
E
R
O
P
E
R
W
X
YZ
W
X
Y
Z
T
U
V
T
U
V
P
Q
R
S
P
Q
R
S
M
N
O
M
N
O
J
K
L
J
K
L
G
H
I
G
H
I
D
EF
D
E
F
A
B
C
A
B
C
S
P
S
P
WARNING! If this entry
system is used to control a
vehicular gate with an
automatic gate operator, the
entry system must be
mounted a minimum of six
(6) feet away from the gate
and gate operator, or in
such a way that a person
cannot operate the entry
system and touch the gate
or gate operator at the same
time.
