1835-065-D-5-17
30
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter for 9600 baud rate or for 19200 baud rate, then press (beep).
3. Press together to end this programming sequence (beeeeeep).
The following programming sequence sets an optional slower RS-232 speed. This feature is available on Rev M boards or
higher and the Remote Account Manager Software, Version 6.3.i, must be used.
Factory setting = 1 (19200 baud rate)
3.2.6 RS-232 Speed Setting
?
?
?
?
5
JKL
8
TUV
0
OPER
1
SP
0
OPER
This new elevator feature authorizes floor access to the Floor Level identified in the Resident Screen in the software program AND
to the floor(s) level identified in the Security Level screen. If this feature is turned off, access will be granted only the floor
identified in the user’s security level. This feature is available on Rev K boards or higher.
Factory setting = 1 (new elevator function is turned ON)
3.2.8 Elevator Control Feature
1. Press and enter your four-digit MASTER CODE (beep).
The LCD display on the 1835 and 1837 systems will read: NEW EL FUNC? 0=N 1=Y
2. Enter for YES (access is authorized to both the floor identified in the resident screen and to the floor(s) identified
in the user’s security level) OR for NO (access is authorized only to the floor(s) identified in the security level
screen), then press (beep).
3. Press together to end this programming sequence (beeeeeep).
?
?
?
?
5
JKL
7
PQRS
0
OPER
1
SP
0
OPER
The following programming sequence sets the switch input (main terminals #4 and #6) to either activate a relay(s) or call the
phone number programmed in directory code 0, 00, 000 or 0000. Refer to section 3.3.4 to determine which relay(s) will activate
when the switch input is activated. This feature is available on Rev K boards or higher.
Factory setting = 0 (switch input activates relay)
3.2.7 Switch Input Feature
1. Press and enter your four-digit MASTER CODE (beep).
The LCD display on the 1835 and 1837 systems will read: KEY IN DIAL? 0=N 1=Y
2. Enter for YES (the switch input will dial a phone number) or for NO (the switch input will activate the relay), then
press (beep).
3. Press together to end this programming sequence (beeeeeep).
?
?
?
?
8
TUV
1
SP
0
OPER
1
SP
0
OPER
This program sequence sets the telephone entry system to operate as a single unit on the phone line, or to share the phone line
with other units. If multiple systems are sharing the same phone line, then each one must be set as a "multiple system" and
each must have a unique master code.
Factory setting = Single System.
3.2.9 Single or Multiple Systems
1. Press and enter your four-digit MASTER CODE (beep).
2. Press (beep) for a single system, OR (beep) for multiple systems.
3. Press together to end this programming sequence (beeeeeep).
?
?
?
?
4
GHI
0
OPER
0
OPER
1
SP
0
OPER
