DoorKing 80 Series Owner's Manual

1835-065-D-5-17
47
3.6 Programming Device Codes
Device codes MUST be five (5) digits in length and are typically used for a remote Wiegand card reader or transmitter devices.
Each device code that you enter must be assigned to a directory code that you select (that was programmed in section 3.5.2).
Up to 25 device codes can be entered under a single directory code, up to a maximum of 8,000 total device codes for the entry
system. The maximum number that can be programmed in is 65405. You cannot duplicate device codes.
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the existing directory code (section 3.5.2 or 3.5.4) that the device code will be assigned to (1, 2, 3 or 4 digits, section
3.5.1), then press (beep).
3. Choose and enter a five-digit device code, then press (beep). (Maximum number that can be programmed in is 65405)
4. Repeat steps 2 and 3 to enter additional device codes. (You cannot duplicate device codes)
5. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
0
0
OPER
OPER
7
7
PQRS
PQRS
0
0
OPER
OPER
This program sequence enters device (card, transmitter, digital) codes into the system memory.
3.6.1 Programming Five-Digit Device Codes
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the existing directory code (section 3.5.2 or 3.5.4) that the desired device code has been assigned to (1, 2, 3 or 4
digits, section 3.5.1), then press (beep).
3. Enter the desired five-digit device code, then press (beep).
4. Repeat steps 2 and 3 to delete additional desired device codes.
5. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
1
1
SP
SP
7
7
PQRS
PQRS
0
0
OPER
OPER
This program sequence deletes individual device codes.
3.6.2 Deleting Device Codes
This program sequence allows you to use (enable) or not use (disable) facility codes.
3.6.3 Enabling Facility Codes
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter (beep) to disable facility codes, or enter (beep) to enable facility codes
3. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
2
2
ABC
ABC
7
7
PQRS
PQRS
0
0
OPER
OPER
0
0
OPER
OPER
1
1
SP
SP
This program sequence enters device facility codes into the system memory. Up to 10 facility codes (reference numbers 0
through 9) may be programmed. Valid facility codes are 000 – 255.
3.6.4 Programming Facility Codes
1. Press and enter your four-digit MASTER CODE (beep).
2. Enter the single-digit first facility code reference number (0 – 9), then press (beep).
3. Enter the three-digit facility code, then press (beep).
4. Repeat steps 2 and 3 to enter additional facility codes.
5. Press together to end this programming sequence (beeeeeep).
?
?
?
?
?
?
?
?
3
3
DEF
DEF
7
7
PQRS
PQRS
0
0
OPER
OPER
