OPERATINGINSTRUCTIONSOperation&MaintenanceManual
Control/GaugePanel
STOP:Stopsthecompressor.
START :Initiatesenginecranking.
SERVICEAIR:Allowsoperatortoload
compressorafterwarm-up.
UP:PressingandreleasingtheUPbuttonscrolls
upthroughparameterlistsandmenuchoicesor
increasesavalueoneitem/unitatatime.Pressing
andholdingtheUPbuttoncontinuouslyscrollsup
throughparameterlists,menuchoicesorincreasesa
valueuntiltheendoftheparameterlist,menuchoices
ormaximumparametervalueisreached.
DOWN:TheDOWNbuttonfunctionsidenticalto
theUPbuttonwiththeexceptionthatitsdirection
foralldisplays,menuchoicesandvaluesisdownor
decreasing.
ENTER:Pressingandreleasingthisbuttonprovides
enterfunctionalitywhenthedisplayrequiresyou
tochooseamenuitem,parameterselectionor
valueinput.Pressingandholdingthisswitchfor
approximatelythreesecondswhileanyoftheMain
ScreensaredisplayedbringsuptheMainMenu.
PressingtheENTERbuttonafteranalertorfaulthas
beendisplayed,acknowledgesthemessageandthe
displayunitreturnstothedefaultscreen.
