Service Manual
Ophthalmic Surgical System
Chapter 2 - Maintenance instructions
14 - Version date: Nov. 01, 2013 - N° doc.: 30204400-B
D.O.R.C. International cannot be held liable for consequential damage if another kind of
packaging is used.
2.6.1 Transport and Packaging the EVA
To transport the EVA please only use the original packaging or the dedicated flight case.
2.6.2 Transport and Packaging modules
To transport a replaced EVA Module please only use the original packaging of the supplied
EVA Module.
2.7 Replacing modules
In the next paragraphs the (dis)assembling is described.
• Covers see par.2.7.2, page15
• Main board see par.2.7.3, page17
• Illumination see par.2.7.4, page18
• Power supply unit see par.2.7.5, page19
• Panel PC see par.2.7.6, page20
• Infusion pole see par.2.7.7, page21
• Phaco/Diathermy see par.2.7.8, page23
• Vitrectome see par.2.7.9, page24
• Posterior unit (VFI/E, Air and Prop. Scissors) see par.2.7.10, page25
• Laser (replacing module) see par.2.7.11, page26
• Laser (power calibration) see par.2.9.1, page30
• Laser (calibration internal power meter) see par.2.9.2, page30
• Pump see par.2.7.12, page29
• Foot pedal see par.2.7.13, page30
2.7.1 Before starting with replacing a module
• Unplug the power cord and the EQP cord;
• Disconnect the compressed air hose;
• To release the pressure still present in the system, push the VGPC connector during approxi-
mately 15 seconds.
