DORC EVA - Modules; Modular System; Overview of Modules; Overview

Service Manual
Ophthalmic Surgical System
Chapter 5 - Modules
38 - Version date: Nov. 01, 2013 - N° doc.: 30204400-B
5 Modules
5.1 Modular system
The EVA is a modular system. In case of a defect the defective module can be replaced by a
new module. The defective module can be returned to D.O.R.C. International for repair.
5.2 Overview of Modules
The electrical schemes of the modules are available upon request only.
5.3 Overview
Module Article Code Module Article Code electrical scheme
Mainboard 23601400 20616500
Pump 23603200 20617200
Phaco - Diathermy 23601800 20616700/20617800
Vitrectomy 23600100 20616300
VFI/VFE - AIR/VGPC - Scissors 23602000 20616900
Illumination 23600000 N/A
Infusion Pole 23601500 20616400
Laser (SMA DORC) 23606500 N/A
Mayo Tray 23610600 N/A
Main Foot Pedal 23591500 N/A
Laser Foot Pedal 23591600 N/A
