Service Manual
Ophthalmic Surgical System
Appendix 1 - Specifications
N° doc.: 30204400-B - Version date: Nov. 01, 2013 - 45
A1.13 Laser Module
Aiming Beam
Working Beam
Specification User Protection Filter
Laser type: Diode Laser
Laser class: II
Wavelength [nm Red]: 625 - 635
Attenuation [mW]: 0 - 1
Laser type:
Frequency doubled, diode pumped Nd:YAG Laser
KTP-laser
Laser class: IV
Wavelength [nm]: 532
Laser power [mW]: 50 up to 1200
Cooling Ambient air
Pulse Duration [ms]: 50 - 5000
Pulse Interval [ms]: 10 - 5000
Laser mode: continuous (CW) / Pulse / Single shot
NOHD for 532nm [m]: 3
Transmission per surface
<0,001% @ 532 nm, AOI = 0°
<0,001% @ 532 nm, AOI = 10°
>90% @ 630 - 640 nm
> 65% @ 460 - 68O nm (average)
Blocking bandwidth SBB < 25 nm, T = 50%
Optical density Better than OD6 @ 532 nm
