DORC EVA - A1.3 Foot Pedal

Service Manual
Ophthalmic Surgical System
Appendix 1 - Specifications
N° doc.: 30204400-B - Version date: Nov. 01, 2013 - 41
A1.3 Foot Pedal
EVA Foot pedal
Laser foot pedal
metric US units
Dimensions [cm] / [inch]:
• Width:
• Height:
• Length:
• 29.5
• 14.3
• 31.9
• 11.6
• 5.6
• 12.6
Weight [kg] / [pounds]: • 4 • 8.8
Protection class: IPX8
Functions:
• 8 switching functions
• 2 analogue functions (vertical pedal
movement and horizontal pedal move-
ment)
metric US units
Dimensions [cm] / [inch]:
• Width:
• Height:
• Length:
• 18.4
• 16.5
• 19.0
• 7.2
• 6.5
• 7.5
Weight [kg] / [pounds]: • 2.3 • 5,1
Protection class: IPX8
Functions:
• 2 switching functions for power setting
• pedal function for laser firing
