Appendix 1 - Specifications
N° doc.: 30204400-B - Version date: Nov. 01, 2013 - 39
Appendix 1 Specifications
This appendix describes the technical details of the EVA.
A1.1 EVA Dimensions
metric US units
EVA Dimensions [cm] / [inch]:
• Width:
• Height:
• Depth:
• 71.7
• 166.7
• 59.5
• 28.2
• 65.6
• 23.4
Weight [kg] / [pounds]
• Eva Anterior Version:
• Eva Posterior Version:
• Eva Posterior Version with laser:
• 122
• 136
• 142
• 269
• 300
• 313
Mayo Tray Dimensions:
• Length fully extended [cm] / [inch]:
(from front of EVA)
• Height (variable) [cm] / [inch]
• Tray [cm] / [inch]:
• Weight [kg] / [pounds]:
• Max load [kg] / [pounds]
• 86.5
• 90 ±15
• 42 x 63.5
• 14
• 8
• 34.1
• 35.5 ±6
• 16.5 x 25
• 31
• 17.5
