Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
97
PROGRAM NUMBER:
109-0305
CONTROLLER
TYPE
I/O
ADDRESS
CONNECTOR
PIN-OUT
DETAILS
REVISION NUMBER:
2016xxxx
HALF/PACK FACTOR AFL 80 I/O RESIDENTIAL
(DEDICATED CAN)
A04
LEFT TURN SIGNAL
MAIN
%IX0.13
P1-39
A05
RIGHT TURN SIGNAL
MAIN
%IX0.11
P1-40
A06
TRANSMISSION TEMP. SIGNAL SWITCH
MAIN
%IX0.15
P1-38
A07
SCALE ALARM-1
MAIN
%IX128.00
P2-55
A08
SCALE ALARM-2
MAIN
%IX128.02
P2-54
IN-CAB OUTPUT FUNCTIONS
B01
CAB ALARM
MAIN
%QX128.08
P2-2
B02
THROTTLE ADVANCE
MAIN
%QX0.10
P1-4
B03
THROTTLE LIMIT
MAIN
%QX0.11
P1-5
B04
WARBLE ALARM
MAIN
%QX128.09
P2-3
B05
HOPPER FLOOD LIGHT
MAIN
%QX128.10
P2-4
BODY INPUT FUNCTIONS
C01
OIL FILTER PRESSURE SWITCH
MAIN
%IX0.06
P1-52
C02
SIDE DOOR CLOSED PROX. SWITCH
MAIN
%IX0.04
P1-53
C03
TAILGATE CLOSED PROX. SWITCH
RTG
%IX0.00
P1-55
C04
LIFT BELOW TRANSIT PROX. SWITCH (2018 COMMERCIAL
HP USE ONLY)
MAIN
%IX0.01
P1-36
C05
FORKS TUCKED PROX. SWITCH (2018 COMMERCIAL HP
USE ONLY)
MAIN
%IX0.03
P1-35
C06
ARMS UP PROX. SWITCH (2018 COMMERCIAL HP USE
ONLY)
MAIN
%IX0.05
P1-34
BODY OUTPUT FUNCTIONS
D01
TAILGATE UP
RTG
%QX0.02
P1-16
D02
TAILGATE DOWN
RTG
%QX0.03
P1-15
D03
TAILGATE LOCK SOLENOID
RTG
%QX0.04
P1-14
D04
TAILGATE UNLOCK SOLENOID
RTG
%QX0.07
P1-11
D05
BACK UP ALARM
MAIN
%QX128.12
P2-6
D06
ARMS UP
MAIN
%QX0.04
P1-14
D07
ARMS DOWN
MAIN
%QX0.05
P1-13
