Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
98
PROGRAM NUMBER:
109-0305
CONTROLLER
TYPE
I/O
ADDRESS
CONNECTOR
PIN-OUT
DETAILS
REVISION NUMBER:
2016xxxx
HALF/PACK FACTOR AFL 80 I/O RESIDENTIAL
(DEDICATED CAN)
D08
CAB PROTECTOR UP
MAIN
%QX0.03
P1-15
D09
CAB PROTECTOR DOWN
MAIN
%QX0.02
P1-16
D10
ALLISON PTO ENABLE
MAIN
%QX0.00
P1-18
D11
PTO 2 SOL
MAIN
%QX0.09
P1-3
D12
PTO 1 SOL
MAIN
%QX0.08
P1-2
D13
CARRY CAN GRAB/COVER CLOSE SOL
MAIN
%QX128.20
P2-29
D14
CARRY CAN RELEASE/COVER OPEN SOL
MAIN
%QX128.21
P2-30
D15
CARRY CAN UP
RCN
%QX0.06
P1-12
D16
CARRY CAN DOWN
RCN
%QX0.05
P1-13
D17
CARRY CAN IN
RCN
%QX0.04
P1-14
D18
CARRY CAN OUT
RCN
%QX0.03
P1-15
D19
CARRY CAN GRAB
RCN
%QX0.02
P1-16
D20
CARRY CAN RELEASE
RCN
%QX0.01
P1-17
D21
TAILGATE FLOW SOLENOID
MAIN
%QX0.14
P1-8
OPTION IN-CAB OUTPUT FUNCTIONS
E01
CAB FLOOD LIGHTS
MAIN
%QX128.00
P2-18
OPTION BODY INPUT FUNCTIONS
F01
HIGH PRESS FILTER INDICATOR
MAIN
%IX128.04
P2-53
F02
BAYNE CAN DOWN
RCN
%IX0.06
P1-52
F03
BAYNE CAN UP
RCN
%IX0.07
P1-33
F04
CAB PROTECTOR DOWN
MAIN
%IX0.14
P1-21
F05
TAILGATE LOCKED PROXIMITY SWITCH
RTG
%IX0.02
P1-54
F06
TOP DOOR OPEN PROXIMITY SWITCH
RTG
%IX0.01
P1-36
F07
OIL LEVEL SWITCH
MAIN
%IX0.07
P1-33
F08
EXTERNAL THROTTLE ADVANCE
MAIN
%IX128.06
P2-52
OPTION IN-CAB OUTPUT FUNCTIONS
G01
CARRY CAN COVER UP
RCN
%QX0.10
P1-4
