Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
99
PROGRAM NUMBER:
109-0305
CONTROLLER
TYPE
I/O
ADDRESS
CONNECTOR
PIN-OUT
DETAILS
REVISION NUMBER:
2016xxxx
HALF/PACK FACTOR AFL 80 I/O RESIDENTIAL
(DEDICATED CAN)
G02
CARRY CAN COVER DOWN
RCN
%QX0.11
P1-5
G03
TAILGATE CAMERA OUTPUT
MAIN
%QX128.03
P2-15
G04
HOPPER CAMERA OUTPUT
MAIN
%QX128.02
P2-16
G05
STROBE LIGHT 1
MAIN
%QX128.14
P2-8
G06
STROBE LIGHT 2
MAIN
%QX128.15
P2-9
G07
TOP DOOR CLOSE
RTG
%QX0.06
P1-12
G08
TOP DOOR OPEN
RTG
%QX0.05
P1-13
G09
CONTAINER FLOOD LIGHT
MAIN
%QX128.11
P2-5
G10
CARRY CAN LIGHTS
RCN
%QX0.07
P1-11
G11
AUXILLIARY BACKUP LIGHT
MAIN
%QX128.13
P2-7
ANALOG INPUT FUNCTIONS
H01
PACKER POSITION
MAIN
%IW4
P1-54
H02
OIL TANK TEMPERATURE
MAIN
%IW14
P1-22
H03
BODY VALVE PRESSURE
MAIN
%IW2
P1-55
OPTION BODY OUTPUT FUNCTIONS
OPEN INPUTS
SPARE INPUT
MAIN
%IX128.01
P2-36
SPARE INPUT
MAIN
%IX128.03
P2-35
SPARE INPUT
MAIN
%IX128.05
P2-34
SPARE INPUT
MAIN
%IX128.07
P2-33
OPEN OUTPUTS
SPARE OUTPUT
MAIN
%QX128.04
P2-14
SPARE OUTPUT
MAIN
%QX128.05
P2-13
SPARE OUTPUT
MAIN
%QX128.06
P2-12
SPARE OUTPUT
MAIN
%QX128.07
P2-11
