Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
100
PROGRAM NUMBER:
109-0305
CONTROLLER
TYPE
I/O
ADDRESS
CONNECTOR
PIN-OUT
DETAILS
REVISION NUMBER:
2016xxxx
HALF/PACK FACTOR AFL 80 I/O RESIDENTIAL
(DEDICATED CAN)
DUAL CONTROL PANEL BOX WHICH FUNCTIONS USING PANEL SELECTOR
SWITCH
CAN IN-CAB INPUT FUNCTIONS
I01
HYDRAULIC PUMP ENABLE PUSH BUTTON
LOWER BANK
I02
PACKER EXTEND PUSH BUTTON
LOWER BANK
I03
PACKER RETRACT PUSH BUTTON
LOWER BANK
I04
PACKER OVERHEIGHT OVERRIDE SWITCH
LOWER BANK
I05
SELECT–O–PACK SWITCH
LOWER BANK
I06
CAB COVER RAISE SWITCH ENABLE
LOWER BANK
I07
CAB COVER LOWER SWITCH ENABLE
LOWER BANK
I08
TAILGATE RAISE ENABLE SWITCH
LOWER BANK
I09
TAILGATE LOWER ENABLE SWITCH
LOWER BANK
I10
TAILGATE LOCK ENABLE SWITCH
LOWER BANK
I11
TAILGATE UNLOCK ENABLE SWITCH
LOWER BANK
I12
AUTOLIFT ENABLE SWITCH
UPPER BANK
MULTI FUNCTION JOYSTICK CONTROLS
J01
JOYSTICK ROCKER (GRABBER) SWITCH
J02
JOYSTICK ROCKER (RELEASE) SWITCH
J03
JOYSTICK Y-AXIS (NEGATIVE DIRECTION)
J04
JOYSTICK Y-AXIS (POSITIVE DIRECTION)
J05
JOYSTICK X-AXIS (NEGATIVE DIRECTION)
J06
JOYSTICK X-AXIS (POSITIVE DIRECTION)
J07
JOYSTICK AUTOLIFT MODE BUTTON
J08
JOYSTICK OPERATOR PRESENCE
OPTION AUXILLIARY-CAB INPUT FUNCTIONS
K01
AUXILLIARY CONTROLS ENABLE SWITCH
K02
AUXILLIARY ARMS RAISE SWITCH
