Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
101
PROGRAM NUMBER:
109-0305
CONTROLLER
TYPE
I/O
ADDRESS
CONNECTOR
PIN-OUT
DETAILS
REVISION NUMBER:
2016xxxx
HALF/PACK FACTOR AFL 80 I/O RESIDENTIAL
(DEDICATED CAN)
K03
AUXILLIARY ARMS LOWER SWITCH
K04
AUXILLIARY FORKS RAISE SWITCH
K05
AUXILLIARY FORKS LOWER SWITCH
K06
AUXILLIARY PACKER EXTEND SWITCH
K07
AUXILLIARY PACKER RETRACT SWITCH
K08
AUXILLIARY CUROTTO CONTROLS ENABLE SWITCH
K09
AUXILLIARY CUROTTO GRAB SWITCH
K10
AUXILLIARY CUROTTO RELEASE SWITCH
K11
AUXILLIARY CUROTTO DUMP SWITCH
K12
AUXILLIARY CUROTTO UNDUMP SWITCH
K13
AUXILLIARY CUROTTO IN SWITCH
K14
AUXILLIARY CUROTTO OUT SWITCH
OPTION CAN IN-CAB INPUT FUNCTIONS
L01
TRAVEL POSITION SWITCH
LOWER BANK
L02
STROBE LIGHT ENABLE SWITCH
UPPER BANK
L03
TOP DOOR OPEN SWITCH
UPPER BANK
L04
TOP DOOR CLOSE SWITCH
UPPER BANK
L05
HOPPER LIGHT ENABLE SWITCH
UPPER BANK
L06
AUXILLIARY LIGHT ENABLE SWITCH
UPPER BANK
L07
CONTAINER LIGHT ENABLE SWITCH
UPPER BANK
L08
CAB LIGHT SWITCH
UPPER BANK
L09
CUROTTO CAN COVER OPEN SWITCH
UPPER BANK
L10
CUROTTO CAN COVER CLOSE SWITCH
UPPER BANK
L11
CAN LIGHT ENABLE SWITCH
UPPER BANK
