Body Controller Software
102
Section 2: J1939 Details
The Engine information is directly read through the SAE J1939 standard. SAE J1939 is the vehicle bus standard used for
communication and diagnostics among vehicle components, like heavy duty truck industry. J1939 is used in heavy vehicles
for on-street and off-road operations and works on the physical layer with CAN-high speed according to ISO11898. J1939
is a multi-master system with decentralized network management without channel-based communication.
J1939 can provide information’s like Engine RPM, Transmission Gear info, Parking Brake Info, and Road Speed.
Section 3: Default Parameters
3.01 Program 109-0305 Parameter Defaults
44
Parameter
Default Setting
A
Start Filter Warning
5 Hours
B
Start Filter Shutdown
6 Hours
C
Packer Extend Auto Pack Time Out
35 Seconds
D
Packer Auto Retract Time Out
35 Seconds
E
Engine Over speed
1800 RPM
F
Engine ON
Engine Speed > 400 RPM
G
Bypass Time Reset
15 minutes
H
Pump Bypass Run Time
180 Seconds
I
Bypass Beep Time
60 Seconds
J
Road Speed Ok
< 5mph
K
Curotto Can Demo Time
3 Seconds
L
Carry Can Stow Time
2 Seconds
M
Throttle Advance
1350 RPM
N
Throttle Limit
1500 RPM
O
Hydraulic Oil Operating Temp
70°F - 190°F
Section 4: I/O Functions
The following sheets detail the functionality of the Input and Output functions provided through the CORTEX32 Controller.
Note: Status of all the Inputs / Outputs can be monitored using the Insight In-Cab display. Refer section 5.04 for more
details about Diagnostic display options and INSIGHT display.
4.01: Standard In-Cab Input Functions
A01 Input Function -- System Power Switch (In Cab Input %IX0.08)
This circuit monitors the ON/OFF status of the system power switch (“mushroom button”).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
