Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
103
Function Logic:
Input Device
Status
I/O Address
Status
System Power Switch
Activated
%IX0.08
ON
A02 Input Function – Chassis Neutral Signal (In Cab Input %IX0.10)
This circuit monitors the transmission Neutral circuit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Chassis Transmission
In Neutral
%IX0.10
ON
A03 Input Function – Panel Selector Switch Enable (In Cab Input %IX0.09)
This signal is used for switching between Street Side and Curb Side Joysticks and panels.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Panel Selector Switch Enable Circuit
Activated
%IX0.09
ON
A04 Input Function – Left Turn Signal Enabled (In Cab Input %IX0.13)
This circuit monitors the status of the Left Turn Signal circuit. This circuit is used for enabling and
disabling Front / Rear strobe circuits.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Turn Signal Enable Circuit
Activated
%IX0.13
ON
A05 Input Function – Right Turn Signal Enabled (In Cab Input %IX0.11)
This circuit monitors the status of the Right Turn Signal circuit. This circuit is used for enabling and
disabling Front / Rear strobe circuits.
Condition
Modifiable Parameters
Default Setting
