Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
104
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Turn Signal Enable Circuit
Activated
%IX0.11
ON
A06 Input Function – Transmission Temperature Signal Switch (In Cab Input %IX0.15)
This circuit monitors the status of the Transmission Oil Temperature. The input is ON when the
Temperature of the Transmission Oil is OK.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Transmission Temperature Switch Circuit
Activated
%IX0.15
ON
A07 Input Function Scale Alarm-1 (In Cab Input %IX128.00)
This circuit monitors the ON/OFF status of the Scale Alarm-1 condition. This Scale Input goes
High (ON) when approaching maximum weight on the scale system.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Scale Alarm-1
Activated
%IX128.00
ON
A08 Input Function Scale Alarm-2 (In Cab Input %IX128.02)
This circuit monitors the ON/OFF status of the Scale Alarm-2 condition. This Scale Input goes
Low (OFF) during overweight condition.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Scale Alarm-2
Activated
%IX128.02
OFF
