Body Controller Software
121
Cab Protector Down Prox. Switch
Activated
%IX0.14
ON
F05 Input Function -- Tailgate Locked Proximity Switch (Body Input %IX0.02)
This circuit monitors the ON/OFF status of the Tailgate Locked Proximity Switch i.e. it indicates the
position of the Tailgate lock cylinders. The input is ON when the Tailgate cylinder is locked.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Tailgate Locked Proximity Switch
Activated
%IX0.02
ON
F06 Input Function – Top Door Fully Open Proximity Switch (Body Input %IX0.01)
This circuit monitors the ON/OFF status of the Top Door Open Proximity Switch. The input is ON
when the top door is fully open.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Top Door Proximity Switch
Activated
%IX0.01
ON
F07 Input Function – Oil Level Switch (Body Input %IX0.07)
This circuit monitors the status of the Hydraulic Oil Level. The input is ON when the Hydraulic Oil Level in
the tank is sufficient. This function is used for activating the Pump.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Oil Level Switch
Activated
%IX0.07
ON
F08 Input Function – External Throttle Advance Switch (Body Input %IX128.06)
This circuit monitors the status of the External Throttle advance switch.
This input is USED FOR FUTURE EXPANSION
Condition
Modifiable Parameters
Default Setting
USED FOR FUTURE EXPANSION
