Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
122
Function Logic:
Input Device
Status
I/O Address
Status
External Throttle Advance Switch
Activated
%IX128.06
ON
4.08: Optional Body Output Functions
G01 Output Function – Curotto - Carry Can Cover Up (Body Output %QX0.10)
This function controls the Curotto - Carry Can Cover Up signal.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Cover Open function
Activated
N/A
ON(See Note below)
B
or Cover Open Push Button
Activated
CAN
ON
C
and Pump On
Activated
N/A
ON
Note: With Condition ‘C’ true, Condition (A OR B) will activate the Carry Can Cover Up output.
Cover Open function will activate automatically for 2 seconds when arms travel below 15 degrees.
G02 Output Function – Curotto - Carry Can Cover Down (Body Output %QX0.11)
This function controls the Curotto - Carry Can Cover Down signal.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Cover Close function
Activated
N/A
ON(See Note below)
B
or Cover Close Push Button
Activated
CAN
ON
C
and Pump On
Activated
N/A
ON
Note: With Condition ‘C’ true, Condition (A OR B) will activate the Carry Can Cover Down output.
Cover Open function will activate automatically for 2 seconds when arms travel above 15 degrees.
G03 Output Function – Tailgate Camera Output (Body Output %QX128.03)
Condition
Modifiable Parameters
Default Setting
A
None
N/A
