Body Controller Software
123
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
NOT USED
G04 Output Function – Hopper Camera Output (Body Output %QX128.02)
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Forks Tucked
Deactivated
N/A
OFF (See Note below)
When the Fork is not in Tucked position and Arm Angle is more than 10 Deg., Hopper camera output is turned ON.
G05 Output Function – Strobe Light 1 Circuit (In Cab Output %QX128.14)
This circuit operates the Strobe light circuit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Strobe Switch Enabled
Activated
CAN
ON
B
Pump On
Activated
N/A
ON
C
Reverse
Activated
N/A
ON
D
Turn Signal
Deactivated
N/A
OFF
Note: The Strobe light circuit-1 can be turned ON in following conditions:
With Pump ON or Reverse signal activated or Strobe switch ON
If the unit is configured with Whelen strobes, the strobes are ON in the above conditions with
Turn signal being deactivated.
G06 Output Function – Strobe Light 2 Circuit (In Cab Output %QX128.15)
This circuit operates the Strobe light circuit -2.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Conditions Necessary to activate the circuit:
Condition
Function or Component
Status
I/O Address
Status
A
Strobe Switch Enabled
Activated
CAN
ON
