Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
126
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Packer Position
Activated
%IW02
VOLTAGE
H02 Input Function – Oil Tank Temperature (Analog Input %IW14)
This circuit measures the Hydraulic Oil Temperature.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Oil Temperature
Activated
%IW14
VOLTAGE
H03 Input Function – Body Valve Pressure (Analog Input %IW0)
This circuit is used to measure the Body Valve pressure.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Body Valve pressure
Activated
%IW0
VOLTAGE
4.10: CAN In-Cab Input Functions
I01 Input Function -- Hydraulic Pump Enable Push Button (CAN - In Cab Input)
This CAN control button is used to turn ON the Hydraulic Pump, either from Street side or from the
Curb side of dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Hydraulic Pump Enable Input
Activated
CAN
ON (CAN Control)
