Dover HEIL Half/Pack Factor AFL - Page 134

Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
128
Function Logic:
Input Device
Status
I/O Address
Status
Select-O-Pack Input
Activated
CAN
ON (CAN Control)
I06 Input Function – CAB Cover Raise Switch Circuit (CAN - In Cab Input)
This CAN control is used to raise the Cab protector shield, either from Street side or from the Curb side of a dual control
panel unit. Future Expansion.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Cab Cover Raise Input
Activated
CAN
ON (CAN Control)
I07 Input Function – CAB Cover Lower Switch Circuit (CAN - In Cab Input)
This CAN control is used to lower the Cab protector shield, either from Street side or from the Curb side
of a dual control panel unit. Future Expansion.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Cab Cover Lower Input
Activated
CAN
ON (CAN Control)
I08 Input Function – Tailgate Raise Switch (CAN - In Cab Input)
This CAN control is used to raise the Tailgate, either from Street side or from the Curb side of a
dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Tailgate Raise Input
Activated
CAN
ON (CAN Control)
I09 Input Function – Tailgate Lower Switch (CAN - In Cab Input)
This CAN control is used to lower the Tailgate, either from Street side or from the Curb side of a
dual control panel unit.
