Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
133
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Arms Lower
Activated
CAN
ON (CAN Control)
K04 Input Function – Auxiliary Forks Raise Switch (CAN - In Cab Input)
This Auxiliary CAN control is used to turn ON the - Forks Raise switch using Auxiliary control. This input
is operative only if Auxiliary Controls Enable Switch is ON (Refer K01).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Forks Raise
Activated
CAN
ON (CAN Control)
K05 Input Function – Auxiliary Forks Lower Switch (CAN - In Cab Input)
This Auxiliary CAN control is used to turn ON the - Forks Lower switch using Auxiliary control. This input
is operative only if Auxiliary Controls Enable Switch is ON (Refer K01).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Forks Lower
Activated
CAN
ON (CAN Control)
K06 Input Function – Auxiliary Packer Extend (CAN - In Cab Input)
This Auxiliary CAN control is used to turn ON the - Packer Extend switch using Auxiliary control. This input is operative only
if Auxiliary Controls Enable Switch is ON (Refer K01).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Packer Extend
Activated
CAN
ON (CAN Control)
