Body Controller Software
134
K07 Input Function – Auxiliary Packer Retract (CAN - In Cab Input)
This Auxiliary CAN control is used to turn ON the - Packer Retract switch using Auxiliary control.
This input is operative only if Auxiliary Controls Enable Switch is ON (Refer K01).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Packer Retract
Activated
CAN
ON (CAN Control)
K08 Input Function – Auxiliary Curotto Control Enable Switch (CAN - In Cab Input)
This is used to turn ON the Auxiliary Curotto Control Enable switch that Enables or Disables the control for
operating the Auxiliary Curotto control.
.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Controls Enable Switch
Activated
CAN
ON (CAN Control)
K09 Input Function – Auxiliary Curotto (GRAB) Switch (CAN - In Cab Input)
Here the Auxiliary Curotto control (GRAB) switch is used to Grab / Hold the Can. This input will be
active only if Auxiliary Curotto Control Enable Switch is ON (Refer K08).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Curotto (Grab) Switch
Activated
CAN
ON (CAN Control)
K10 Input Function – Auxiliary Curotto (RELEASE) Switch (CAN - In Cab Input)
Here the Auxiliary Curotto control (RELEASE) is used to release the Can from Gripper. This input will be
active only if Auxiliary Curotto Control Enable Switch is ON (Refer K08).
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
