Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
136
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Curotto (OUT) Switch
Activated
CAN
ON (CAN Control)
4.13: OPTION CAN In-Cab Input Functions
L01 Input Function – Travel Position Switch (CAN - In Cab Input)
This CAN control is used to turn ON/OFF the Travel position Signal of the Packer, either from Street side or from the Curb
side of a dual control panel unit. This switch is used to move the Packer to the travel position when there is no top door.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Travel Position Switch
Activated
CAN
ON (CAN Control)
L02 Input Function – Strobe Light Switch (CAN - In Cab Input)
This CAN control is used to turn ON/OFF the Strobe Light Circuit, either from Street side or from the
Curb side of a dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Strobe Light Circuit Switch
Activated
CAN
ON (CAN Control)
L03 Input Function – Top Door Open Switch (CAN - In Cab Input)
This CAN control is used to open the Top Door, either from Street side or from the Curb side of a dual
control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Top Door Open Switch
Activated
CAN
ON (CAN Control)
