Half/Pack
®
Issued April 2018
Body Controller Software
Copyright 2018, Heil Environmental
Printed in the U.S.A.
Body Controller Software
137
L04 Input Function – Top Door Close Switch (CAN - In Cab Input)
This CAN control is used to close the Top Door during the Travel position Signal of the Packer, either from
Street side or from the Curb side of a dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Top Door Close Switch
Activated
CAN
ON (CAN Control)
L05 Input Function – Hopper Light Switch (CAN - In Cab Input)
This CAN control is used to turn ON/OFF the Hopper Light Circuit, either from Street side or from the
Curb side of a dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Hopper Light Circuit Switch
Activated
CAN
ON (CAN Control)
L06 Input Function – Auxiliary Light Switch Circuit (CAN - In Cab Input)
This CAN control is used to turn ON/OFF the Auxiliary Backup Light Circuit, either from Street side or from
the Curb side of a dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
Function Logic:
Input Device
Status
I/O Address
Status
Auxiliary Backup Light Circuit Switch
Activated
CAN
ON (CAN Control)
L07 Input Function – Container Light Switch Circuit (CAN - In Cab Input)
This CAN control is used to turn ON/OFF the Container Light Circuit, either from Street side or from the
Curb side of a dual control panel unit.
Condition
Modifiable Parameters
Default Setting
A
None
N/A
