Body Controller Software
167
Insight Display Illustration:
Indication: Low Hydraulic Oil Level
Disabled Functions: Hydraulic Pump
Fault Reset: Refill hydraulic oil tank.
Oil Over Temperature Shutdown Fault (standard equipment)
If the Hydraulic Oil temperature is greater than 190º F, then the diagnostic message will be displayed in the Insight
display. This is recognized as a fault because the Oil temperature should always be within the specified limit (Less
than 190 º F) for the system to function properly.
Insight Display Illustration:
Indication: A. Hydraulic Oil over temperature shutdown.
Disabled Functions: Hydraulic Pump
Fault Reset: Reduce temperature before operation.
