Half/Pack
®
Issued April 2018
General Information
Copyright 2018, Heil Environmental
Printed in the U.S.A.
General Information
18
TORQUE FOR HYDRAULIC TUBES AND FITTINGS (CONTINUED)
FROM SAE J2593 TABLE 7
BOSS (ORB)
(STEEL) SET WRENCH TO
NOMINAL TUBE OD
TORQUE WRENCH SETTING
ALTERNATE TORQUE UNITS
3/16"
9 ft-lbs.
110 in-lbs.
1/4"
16.5 ft-lbs.
200 in-lbs.
5/16"
21 ft-lbs.
250 in-lbs.
3/8"
29 ft-lbs.
350 in-lbs.
1/2"
64 ft-lbs.
770 in-lbs.
5/8"
89 ft-lbs.
1070 in-lbs.
3/4"
130 ft-lbs.
1560 in-lbs.
7/8"
178.5 ft-lbs.
2140 in-lbs.
1"
224 ft-lbs.
2690 in-lbs.
1-1/4"
250 ft-lbs.
3000 in-lbs.
1-1/2"
300 ft-lbs.
3600 in-lbs.
ALUMINUM SET
TORQUE WRENCH SETTING
ALTERNATE TORQUE UNITS
6 ft-lbs.
70 in-lbs.
11 ft-lbs.
130 in-lbs.
14 ft-lbs.
170 in-lbs.
21 ft-lbs.
250 in-lbs.
37.5 ft-lbs.
450 in-lbs.
54 ft-lbs.
650 in-lbs.
91.5 ft-lbs.
1100 in-lbs.
116.5 ft-lbs.
1400 in-lbs.
146 ft-lbs.
1750 in-lbs.
154 ft-lbs.
1850 in-lbs.
200 ft-lbs.
2400 in-lbs.
