88 Dover Fueling Solutions W2940305 Rev 07 8/2019
Function Number & Name Sub-function Number & Description
Configuration
Setting
Std.
Model
w/ Pulse
Output
.09 Maintenance mode access thru Remote w/o
pressing the CRC button on iGEM first
0=Entry possible at all levels
1=Entry with button 1,2,5 CLR w/o CRC
2=Entry with button 5 and CLR w/o CRC
3=Reserved
4=Entry with button 5 w/o CRC
5=No entry w/o pressing CRC button first
6=Entry with button 1 w/o CRC
7=Reserved
8=Entry with button CLR w/o CRC
0
F22 Sales Amount
Calculation
.00 Denomination ratio between money display
and unit price display
1 =1/1
2 =10/1
3 =100/1
4 =1/10
5 =1/100
6 =1/1000
1
.01 Count by ones or fives in least significant
digit of money display
1=Ones
2=Fives
1
.02 Volume digits to the right of the decimal point
used in the amount calculation 0-5, 5 = use
volume decimal point as defined in function
14.3
5
.03 Money preset configuration 0
.04 Default price mode
1=Credit
2=Cash
1
F23 Miscellaneous Timers .00 Display test time (test time also known as
valve on delay), 2-24 units of ½ sec
6
.01 Minimum time between fillings, 0-20 units of
½ sec., 0 = disabled
0
.02 Stop for offline error, 0-30 sec., 0 = disabled 0
.03 Max. time allowed for filling, 0-60 min., 0 =
disabled
0
.04 Time from unit price change until next start of
sale, 0-15 sec.
0
.05 Unit price display backlight dimming control
timer, 0=disabled, XX=minutes of idle time
prior to dimming backlight
0
.06 Error display timer, XX=minutes to display
current error code (see F07.09) 1-254
minutes, 255=display until next transaction
255
F24 Local Preset Operating
Configuration
.00 Preset operation
1=Money only
2=Volume only
3=Default to money
4=Default to volume
2
.01 Preset entry required before filling
1=Preset required
2=Preset not required
2
.02 Fill mode display
1=Display “------“ when fill key pressed
2=Display “FILL” when fill key pressed
2
