DSE Model 560 Automatic Start Engine Management and Instrumentation System Operators Manual
560 OPERATING MANUAL ISSUE 5 4/4/02 MR 25
6. SPECIFICATION
DC Supply
9.0 to 35 V Continuous.
Cranking Dropouts
Able to survive 0 V for 50 mS, providing supply was at least
10 V before dropout and supply recovers to 5V
.This is
achieved without the need for internal batteries.
Max. Operating Current
390mA at 12 V. 250mA at 24 V.
Max. Standby Current
220mA at 12 V. 120mA at 24 V.
Alternator Input Range
3Phase 4Wire System
3Phase 3Wire System
15V - 277 (ph-N) 3 Phase 4wire AC (+20%)
30V - 480 (ph-ph) 3 Phase 3wire AC (+20%)
Alternator Input Frequency
50 - 60 Hz at rated engine speed
Magnetic Input Range (if fitted)
+/- 0.5 V to 70 V Peak
Magnetic Input Frequency
10,000 Hz (max) at rated engine speed.
Start Relay Output
16 Amp DC at supply voltage.
Fuel Relay Output
16 Amp DC at supply voltage.
Auxiliary Relay Outputs
5 Amp DC at supply voltage.
Dimensions
192 X 144 X 138
Charge Fail / Excitation Range
0 V to 35 V
Operating Temperature Range
-30 to +70°C
CT Burden
2.5VA
CT Secondary
5A
CT Class
Class 1 Recommended
Electromagnetic Compatibility
BS EN 50081-2 EMC Generic Emission Standard (Industrial)
BS EN 50082-2 EMC Generic Emission Standard (Industrial)
Electrical Safety
BS EN 60950
Cold Temperature
BS EN 60068-2-1 to -30
o
C
Hot Temperature
BS EN 60068-2-2 to +70
o
C
Humidity
BS2011-2-1 to 93% RH@40
o
C for 48 Hours
Vibration
BS EN60068-2-6
10 sweeps at 1 octave/minute in each of 3 major axes.
5Hz to 8Hz @ +/-7.5mm constant displacement
8Hz to 500Hz @ 2gn constant acceleration
Shock
BS EN 60068-2-27
3 Half sine shocks in each of 3 major axes
15gn amplitude, 11mS duration
