1. OPERATION
1.1 CONTROL
Control of the DSE 560 module is via a rotary switch (or Key-switch) mounted on the front of the
module with STOP/RESET, MANUAL and AUTO functions. For normal operation this is the only
control which needs to be operated. The small push-button is used to access further information
such as instrumentation, details of its operation are detailed later in this document.
The following description detail the sequences followed by a module containing the standard
‘factory configuration’. Always refer to your configuration source for the exact sequences and
timers observed by any particular module in the field.
O
AUTO
o
F
o
CRPMPSI
88 88 88 88 88 88
AV
L3
BAR
L1 L2 L2 N L1N L3 N
Hz
A
V
V
Deep Sea Electronics plc
Model 560
FIG 1
