DSE Model 560 Automatic Start Engine Management and Instrumentation System Operators Manual
560 OPERATING MANUAL ISSUE 5 4/4/02 MR 29
10. FACTORY DEFAULT CONFIGURATION
P560 Configuration
Title: Standard default settings factory set
Created by: Miles Revell
Date: 17 January 2000
Filename: P560A
MISCELLANEOUS ITEMS
Item Value
Magnetic pickup input present No
Flywheel teeth 190
Alternator frequency input present Yes
Alternator poles 4
Start attempts 3
AC System Three Phase, Four Wire
Enable Fast Loading Yes
Check Oil Pressure for engine at rest Yes
CT Primary 500
Enable High Current Warning Yes
High Current Warning 125%
INPUTS
Low oil pressure VDO 0-10Bar
Low oil pressure Shutdown (PSI) 20
High engine temp. VDO 120 deg C
High engine temp. Shutdown (
o
C) 110
Input channel Polarity Type Activation time
Auxiliary input 1 Close to activate Remote Start
Auxiliary input 2 Close to activate Indication Always Active
Auxiliary input 3 Close to activate Shutdown Active from Safety On
Auxiliary input 4 Close to activate Warning Active from Safety On
Auxiliary input 5 Close to Activate Warning Always active
OUTPUTS
Output channel Polarity Control source
Auxiliary output 1 Energise 1 Pre-heat
Auxiliary output 2 Energise 35 Common alarm
Auxiliary output 3 Energise 4 Load transfer
Expansion output 1 Energise 00 Unused
Expansion output 2 Energise 00 Unused
Expansion output 3 Energise 00 Unused
Expansion output 4 Energise 00 Unused
Expansion output 5 Energise 00 Unused
Expansion output 6 Energise 00 Unused
Expansion output 7 Energise 00 Unused
Expansion output 8 Energise 00 Unused
LCD Indicators
LCD Polarity Control source
LCD 1 Lit 39 Remote start present
LCD 2 Lit 43 Auxiliary IP 2 active
LCD 3 Lit 44 Auxiliary IP 3 active
LCD 4 Lit 45 Auxiliary IP 4 active
To Next Page
