DSE Model 560 Automatic Start Engine Management and Instrumentation System Operators Manual
560 OPERATING MANUAL ISSUE 5 4/4/02 MR
30
SYSTEM TIMERS
Timer Mins:secs
Remote start delay time 0:05
Remote stop delay time 0:30
Cranking time 0:10
Crank rest time 0:10
Safety on delay time 0:10
Warm up time 0:00
Cooling time 0:30
Fail to stop time 0:30
ETS solenoid hold time 0:00
Pre-heat time 0:00
Sensor fail delay time 0:02
Smoke limiting time 0:00
Smoke limiting ramp time 0:00
Low DC Volts Delay 01:00
Speed / Frequency
Level Value
Over frequency 57.0 Hz
Overspeed on magnetic pickup 1750 RPM
Overspeed overshoot during safety on delay 2 %
Under frequency 30.0 Hz
Under-speed on magnetic pickup 1250 RPM
Crank disconnect on alternator frequency 21.0 Hz
Crank disconnect on magnetic pickup 600 RPM
Voltage Settings
Level Value
Undervolts trip 180.0V AC
Overvolts trip 265.0 V AC
Under Volts Alarm 9.0V DC
Charge Fail 8.0V DC
Crank disconnect charge alternator voltage 40.0 V DC
Over Volts Alarm 33.0V DC
