DSE Model 560 Automatic Start Engine Management and Instrumentation System Operators Manual
560 OPERATING MANUAL ISSUE 5 4/4/02 MR
16
LCD DISPLAY AREAS
NOTE:- The Engine Hours Run counter will only display the accumulated hours to the
nearest 12 Minutes Hour (0.2Hr). The accumulated time will be recorded in HH:MM
however. [Pre V1.4 Modules recorded hours run to the nearest ½ Hour (0.5)]
CAUTION!:-If the DC supply to the module is interrupted the hours run counter will not
remember any ‘un-displayed’ minutes accumulated since the last 12 Minute display update.
i.e.
10 Hours 38 Minutes accumulated before DC supply is removed…
(10.6 Hours displayed)
would become …10 Hours 36Minutes on restoration of DC supply.
(10.6 Hours still displayed)
This will only occur in the event of a total DC supply break and will NOT occur if the module
is simply switched to the Stop/Reset position.
Instrument Values
Units of Measure
Display Information &
