DSE Model 560 Automatic Start Engine Management and Instrumentation System Operators Manual
560 OPERATING MANUAL ISSUE 5 4/4/02 MR
26
7. COMMISSIONING
7.1 PRE-COMMISSIONING
Before the system is started, it is recommended that the following checks are made:-
7.1. The unit is adequately cooled and all the wiring to the module is of a standard and rating
compatible with the system.
7.2. The unit
DC supply is fused and connected to the battery and that it is of the correct polarity.
7.3. The Emergency Stop input is wired to an external normally closed switch connected to DC
positive.
NOTE:- If Emergency Stop feature is not required link this input to the DC Positive. The
module will not operate unless either the Emergency Stop is fitted correctly OR Pin 3 is
connected to DC positive (+ve)
7.4. To check the start cycle operation take appropriate measures to prevent the engine from
starting (disable the operation of the fuel solenoid). After a visual inspection to ensure it is
safe to proceed, connect the battery supply. Select
“MANUAL”, the unit start sequence will
commence.
7.5. The starter will engage and operate for the pre-set crank period. After the starter motor has
attempted to start the engine for the pre-set number of attempts the
LCD will display it’s icon
indicating; ‘
Shutdown Failed to start’. Select the STOP/RESET position to reset the unit.
7.6. Restore the engine to operational status (reconnect the fuel solenoid), again select
“MANUAL”, this time the engine should start and the starter motor should disengage
automatically. If not then check that the engine is fully operational (fuel available, etc.) and
that the fuel solenoid is operating. The engine should now run up to operating speed. If not,
and an alarm is present, check the alarm condition for validity, then check input wiring. The
engine should continue to run for an indefinite period. It will be possible at this time to view
the engine and alternator parameters - refer to the ‘Description of Controls’ section of this
manual.
7.7. Select
“AUTO” on the front panel, the engine will run for the pre-set cooling down period,
then stop. The generator should stay in the standby mode. If not check that there is not a
signal present on the
Remote Start input.
7.8. Initiate an automatic start by supplying the remote start signal. The start sequence will
commence and the engine will run up to operational speed. Once the generator is available a
load transfer will take place, the Generator will accept the load. If not, check the wiring to the
Generator Contactor Coil
(if used). Check the Warming timer has timed out.
7.9. Remove the remote start signal, the return sequence will start. After the pre-set time period,
the load will be removed from the generator. The generator will then run for the pre-set
cooling down period, then shutdown into it’s standby mode.
7.10. If despite repeated checking of the connections between the
560 and the customer’s system,
satisfactory operation cannot be achieved, then the customer is requested to contact the
factory for further advice on:-
INTERNATIONAL TEL: +44 (0) 1723 377566
INTERNATIONAL FAX: +44 (0) 1723 354453
E-mail: Support@Deepseaplc.com
