DSE 560 - Plug C 4 Way; PC Configuration Interface Connector

DSE Model 560 Automatic Start Engine Management and Instrumentation System Operators Manual
560 OPERATING MANUAL ISSUE 5 4/4/02 MR
22
PLUG “C” 4 WAY
PIN
No
DESCRIPTION CABLE
SIZE
NOTES
31 Generator L1 Voltage
Monitoring Input
1.0mm Connect to generator L1 output (AC)
(Recommend 2A Fuse)
32 Generator L2 Voltage
Monitoring Input
1.0mm Connect to generator L2 output (AC)
(Recommend 2A Fuse)
33 Generator L3 Voltage
Monitoring Input
1.0mm Connect to generator L3 output (AC)
(Recommend 2A Fuse)
34 Generator Neutral Input 1.0mm Connect to generator Neutral output (AC)
NOTES:-
Screened cable must be used for connecting the Magnetic Pickup, ensuring that the
screen is earthed at one end ONLY.
A version of the module is available which allows connection to a 3 phase 3 wire system
with no neutral (Delta). If using such a module then no connection should be made to
terminal 34.
PC CONFIGURATION INTERFACE CONNECTOR
4-way connector allows connection to PC via the 808 configuration interface.
Module can then be re-configured utilising the P808 for Windows™ software.
The connector also allows connection to the 157 relay expansion module or to
the 548 LED Remote annunciator module.
:
::
:
