Front Panel Configuration
110
11.1.2 ADJUSTABLE PARAMETERS
Front Panel Configuration Editor. For descriptions of the parameters, you are referred to The DSE8600 series
Configuration Suite Manual, DSE Part 057-119.
Section Parameter as shown on display Values
Display
Contrast 53%
Language
English, others.
Current Date and Time
hh:mm
Timers
LCD Page Timer
5m
Scroll Delay
2s
Engine Pre Heat Timer
0s
Engine Crank Duration
10s
Engine Crank Rest Time
10s
Engine Safety On Delay
10s
Engine Smoke Limiting
0s
Engine Smoke Limiting Off
0s
Engine Warm Up Time
1s
Engine Cool Down Time
1m
Engine Speed Overshoot Delay
0s
Engine Failed To Stop
30s
Battery Under Voltage Warning Delay
1m
Battery Over Voltage Warning Delay
1m
Return Delay
30s
Generator Transient Delay
0s
Generator
Under Voltage Shutdown
184v
Under Voltage Pre-Alarm
196v
Loading Voltage 207
Nominal Voltage 230v
Over Voltage Pre-Alarm 265v
Over Voltage Shutdown 277v
Under Frequency Shutdown 40Hz
Under Frequency Pre-Alarm 42Hz
Short Circuit Trip 200%
Loading Frequency 45Hz
Nominal Frequency 50Hz
Over Frequency Pre-Alarm 54Hz
Over Frequency Shutdown 57Hz
Full Load Rating 500A
KW Overload Trip 100%
Delayed Over current Active
Gen Over Current Trip 100%
AC System 3 Phase 4 Wire
CT Primary 600A
CT Secondary 5A
Short Circuit Trip 200%
Earth CT Primary 500A
Earth Fault Trip Active
Earth Fault Trip 10%
Transient Delay 0s
Gen Reverse Power Delay 2s
Full kW rating 345kW
Full kVAr rating 258kVAr
Load Ramp Rate 3%
Load Level For More Sets 80%
Load Level For Less Sets 70%
Load Demand Priority 1
Gen Reverse Power Trip 35kW
Gen Over Current 0%
Insufficient Capacity Delay 1s
Insufficient Capacity Action None
Reactive Load CTL Mode VAr Share None
Load Parallel Power 172kW When In Mains Parallel Mode
Load Power factor 0% When In Mains Parallel Mode
Enable 75/55 MSC Compatibility Inactive
Engine
Oil Pressure Low shutdown 1.03bar
Oil Pressure Low Pre-Alarm 1.17bar
Coolant Temp High Pre-Alarm 90ºC
Coolant Temp High Electrical Trip 92ºC
Coolant Temp High Shutdown 95ºC
Start Delay Off load 5s
Start Delay on load 5s
Start Delay mains fail 0s
Start Delay Telemetry 5s
Pre Heat Timer 0s
Crank Duration 10s
Crank rest Time 10s
Safety On Delay 10s
Smoke Limiting 0s
Smoke limiting off 0s
Warm Up Time 1s
Cool Down Time 1m
Speed Overshoot Delay 0s
Speed Overshoot 0%
Fail To Stop Delay 30s
Battery Under Volts Warning Active
Battery Under Volts Warning Delay 1m
Battery Under Volts Warning 19v
Battery Over Volts Warning Active
Battery Over Volts Warning Delay 1m
Battery Over Volts Warning 30v
Charge Alternator Failure Warning Active
Charge Alternator Failure Warning 6.0v
Charge Alternator Warning Delay 5s
Charge Alternator Failure Shutdown Active
Charge Alternator Failure Shutdown 4.0
Charge Alternator Shutdown Delay 5s
Droop %
Active, Inactive. Electronic engines only when droop is
enabled.
Scheduler
Scheduler Active, Inactive
Schedule On Load
Active , Inactive (Only Available When Scheduler Is
Active)
Schedule Period Weekly, Monthly (Only Available When Scheduler Is Active)
Schedule Time & Date Selection (1-16)
Press to begin editing then press or when
selecting the different parameters in the scheduler.
