15 MAINTENANCE, SPARES, REPAIR AND SERVICING
The DSE8600 Series controller is Fit and Forget. As such, there are no user serviceable parts within the controller.
In the case of malfunction, you should contact your original equipment manufacturer (OEM).
15.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE
If you require additional plugs from DSE, please contact our Sales department using the part numbers below.
Individual plugs
8600 series terminal designation Plug description Part No.
1-13
13 way 5.08mm 007-166
15-19
5 way 5.08mm 007-445
22-38
MSC GOV AVR
17 way 5.08mm 007-452
39-46
V1 8 way 7.62mm 007-454
47-50
V2
4 way 7.62mm 007-171
51-57
7 way 5.08mm 007-447
60-70
11 way 5.08mm 007-451
PC Configuration interface lead
(USB type A – USB type B)
016-125
NOTE:- Terminals 20, 21, 58 and 59 are not fitted to DSE8600 series controllers.
15.2 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE
Item Description Part No.
8600 series fixing clips (packet of 4) 020-294
15.3 PURCHASING ADDITIONAL SEALING GASKET FROM DSE
Item Description Part No.
8600 series silicon sealing gasket 020-507
