FLEXIBLE BATCH BROILER
EQUIPMENT
MANUAL
April 1, 2007
C-2. Daily Cleaning (cont’d)
Discharge Scraper: Pull out
removing locating pins from slots.
Clean scraper and area. Replace.
Discharge Scraper: Lift up and pull
forward.
Discharge End Panel: Remove
discharge accessories and lift panel up
while swinging out and down.
Clean the top of the burner
with the brush end of the
“Tube Burner Cleaning Tool”.
For heavy build-up, use the
scraper end of the “Tube
Burner Cleaning Tool”.
Use the end of the tool to
clean the discharge shaft of
the conveyor.
To Next Page
