Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 106 of 165 TD/TAD4 Manual Rev 4
ITEM
QTY.
DESCRIPTION
TD410
TD415
TD420
PART No.
PART No.
PART No.
1
1
T4 HINGE CASTING
GA8714
GA8714
GA8714
2
1
T4 VANE CASTING
GA8715
GA8715
GA8715
3
1
T4 IMPELLOR
GA8765
GA8764
GA8763
4
1
T4 FAN MOTOR
MOTORF01210
MOTORF01230
MOTORF01250
5
1
T4 PLAIN CASTING
GA8716
GA8716
GA8716
6
1
T4 INNER SHUTTER
GA15126
GA15126
GA17210
7
1
T4 OUTER SHUTTER
GA15127
GA15127
GA17290
8A
1
T4 SILENCER
GA8891
GA8891
GA8892
8B
1
T4 CHAMFERED SNORKEL SILENCER
GA21875
GA21875
GA21504
9
4
MOD PLATE SPACER
GA7961
GA7961
GA7961
10
1
T4 MOD PLATE
GA17188
GA17188
GA17188
11
1
RATIOTRONIC 6027 SERVO MOTOR
ETCRAT00745
ETCRAT00745
ETCRAT00745
12
1
CABINET HANGER PLATE
GA9093
GA9093
GA9093
13
1
CP552 UNIVERSAL HANDED BURNER
CABINET
GA19714
GA19714
GA19714
14
1
CP552 CABINET DOOR
GA10722
GA10722
GA10722
15
1
1/4" x 10mm SWIVEL ELBOW
COMPAD00505
COMPAD00505
COMPAD00505
16
-
n10MM BUNDI TUBE
BUNDIT00090
BUNDIT00090
BUNDIT00090
17
1
1/4" BSP x 10mm MALE STUD COUPLING
COMPAD00485
COMPAD00485
COMPAD00485
18
1
LGW50 A2P PRESSURE SWITCH
PRESWI00245
PRESWI00245
PRESWI00245
19
1
DN80 GASKET
GASKET00970
GASKET00970
GASKET00970
20
1
QRA2 UV CELL AND BRACKET
12041
12041
12041
21
1
FAN HUB FOR T4 BURNER
GA8767
GA8767
GA8767
22
1
T4 BOILER MOUNTING GASKET
GA11741
GA11742
GA11742
23
1
T4 MULTI-FLAME MOUNTING SECTION
GA20040
GA20134
GA20134
24
1
T415 - 420 MULTI-FLAME MOUNTING
SECTION NOSE CONE
GA20042
GA20135
GA20135
25
1
T4 AIR GUIDE VANE (WHEN FITTED)
GA22534
GA22534
GA22534
26
3
T4 MULTI-FLAME SPLIT BLOCK
GA19506B
GA19506B
GA19506B
27
22
1/8" BSP DOWTY SEAL
SEADOW00050
SEADOW00050
SEADOW00050
28
14
1/8" BSP x 6mm MALE STUD COUPLING
COMPAD00105
COMPAD00105
COMPAD00105
29
-
n6mm BUNDI TUBE
BUNDIT00070
BUNDIT00070
BUNDIT00070
30
8
1/8" BSP NON - RETURN VALVE
VALVCH00220
VALVCH00220
VALVCH00220
31
8
1/8" BSP x 6mm STANDPIPE ADAPTOR
COMPAD00280
COMPAD00280
COMPAD00280
32
3
ART106 BURNER GUN NOZZLE BLOCK
ASSEMBLY - OUTER NOZZLE
GA20137
GA20137
GA20137
33
1
T4 MULTI-PIPE HEAD
GA22262
GA20136
GA20136
34
3
M5 FLAT COPPER WASHER
COPWAS00025
COPWAS00025
COPWAS00025
35
1
OIL SHELL HEAD FOR MULTI-OIL DUAL FUEL
BURNERS
GA22263
GA18784
GA18784
36
1
TD4 MULTI-OIL MULTI-GAS FLAMEPLATE
GA22662
GA22196
GA22196
37
4
ELECTRODE SPLIT BUSH
GA8264
GA8264
GA8264
38
2
GAS IGNITION ELECTRODES
IGELEC00100
IGELEC00100
IGELEC00100
39
2
ORING, BS206 VITON
ORINGS00180
ORINGS00180
ORINGS00180
40
1
ORING VITON 0695-30
ORINGS01025
ORINGS01025
ORINGS01025
41
1
T3-T5 OIL BURNER SANDWICH BLOCK -
PART A
GA9178A
GA9178A
GA9178A
42
1
T3-T5 OIL BURNER SANDWICH BLOCK -
PART B
GA9178B
GA9178B
GA9178B
43
2
1/4" BSP x 6mm MALE STUD COUPLING
COMPAD00620
COMPAD00620
COMPAD00620
44
4
MOD PLATE SPACERS
GA7961
GA7961
GA7961
