Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 107 of 165 TD/TAD4 Manual Rev 4
45
1
PUMP MOTOR MOUNTING BRACKET
GA9562
GA9562
GA9562
46
1
PUMP MOTOR
MOTPUM00220
MOTPUM00220
MOTPUM00300
47
1
PUMP MOTOR HOUSING
GA5900
GA5900
GA9740
48
1
DH PUMP VALVE BRACKET
GA10190
GA10190
GA10228
49
1
DH OIL PUMP SERIES
PUMDUN01021
PUMDUN01021
PUMDUN02015
50
2
No.3 BANJO BOLT
GA10125
GA10125
GA10125
51
1
No.1 BANJO MANIFOLD BLOCK
GA16777
GA16777
GA16777
52
13
1/2" BSP DOWTY SEAL
SEADOW00110
SEADOW00110
SEADOW00110
53
2
1/2" BSP N/C LUCIFER OIL VALVE
SOLOIL00240
SOLOIL00240
SOLOIL00240
54
5
1/2" BSP x 10mm MALE STUD COUPLING
-
-
COMPAD00300
1/4" BSP x 10mm MALE STUD COUPLING
COMPAD00485
COMPAD00485
-
55
1
1/4" BSP YORKSHIRE FITTING
YORFIT00510
YORFIT00510
YORFIT00510
56
1
MANIFOLD BANJO BLOCK
GA16780
GA16780
GA16771
57
1
MANIFOLD BANJO BOLT A
GA10382
GA10382
GA10400
58
1
MANIFOLD BANJO BOLT B
GA10143
GA10143
GA10401
59
3
1/2" BSP x 10mm STANDPIPE ADAPTOR
COMPAD00520
COMPAD00520
COMPAD00520
60
2
3/8" BSP x 10mm MALE STUD COUPLING
COMPAD00490
COMPAD00490
COMPAD00490
61
4
3/8" BSP DOWTY SEAL
SEADOW00100
SEADOW00100
SEADOW00100
62
2
1/2" BSP SRV OIL SOLENOID VALVE
SOLOIL00360
SOLOIL00360
SOLOIL00360
63
8
10mm EQUAL TEE PIECE
COMPAD00520
COMPAD00520
COMPAD00520
64
1
10mm EQUAL ELBOW
COMPAD00435
COMPAD00435
COMPAD00435
65
2
VT2 METERING VALVE ASSEMBLY
GA16090
GA16090
GA16090
66
2
RATIOTRONIC 6026 SERVO MOTOR
ETCRAT00720
ETCRAT00720
ETCRAT00720
67
1
TWIN VT2 METERING VALVE MOUNTING
BRACKET
OILMET00753
OILMET00753
OILMET00753
68
16
1/4" BSP x 10mm MALE STUD COUPLING
COMPAD00485
COMPAD00485
COMPAD00485
69
24
1/4" BSP DOWTY SEAL
SEADOW00105
SEADOW00105
SEADOW00105
70
5
1/4" BSP x 10mm STANDPIPE ADAPTOR
COMPAD00535
COMPAD00535
COMPAD00535
71
3
1/4" BSP MINI OIL BALL VALVE
VALOIL00110
VALOIL00110
VALOIL00110
72
3
0 - 41 BAR (0-600 PSI) PRESSURE GAUGE
PRESGA00155
PRESGA00155
PRESGA00155
73
2
PRESSURE SWITCH ADAPTOR (1/4" BSP - 1/2"
BSP REDUCER)
BANMAN00170
BANMAN00170
BANMAN00170
74
1
HIGH OIL PRESSURE SWITCH (SAUTER)
HIGH OIL PRESSURE SWITCH (BAILEY)
PRESWI00570
PRESWI00700
PRESWI00570
PRESWI00700
PRESWI00570
PRESWI00700
75
2
3/8" BSP x 10mm STANDPIPE ADAPTOR
COMPAD00540
COMPAD00540
COMPAD00540
76
1
DH OIL PUMP MOUNTING FLANGE
-
-
PUMFLA00120
77
2
3/4" BSP DOWTY SEAL
SEADOW00120
SEADOW00120
SEADOW00120
78
1
3/4" BSP x 1" BSP REDUCING NIPPLE
-
-
PIPNIP01450
1/2" BSP x 3/4" BSP REDUCING NIPPLE
PIPNIP01430
PIPNIP01430
-
79
1
3/4" BSP x 1" BSP POSITIONABLE ELBOW
-
-
CONELB00135
1/2" BSP x 3/4" BSP POSITIONABLE ELBOW
CONELB00125
CONELB00125
-
80
1
1/2" COPPER WASHER
COPWAS00110
COPWAS00110
COPWAS00110
81
2
3/4" COPPER WASHER
COPWAS00115
COPWAS00115
COPWAS00115
82
3
NYLON ROLLER
GA5761A
GA5761A
GA5761A
83
3
STEEL BUSH FOR NYLON ROLLER
GA5761B
GA5761B
GA5761B
84
1
BRIDGE HANDLE
CONTOL02285
CONTOL02285
CONTOL02285
85
1
PUMP COUPLING & INSERT ASSEMBLY
(CHALLENGE)
PUMZCP00665
PUMZCP00665
PUMZCP00665
86
1
COVER PLATE FOR PUMP HOUSING
GA6707
GA6707
GA6707
87
1
10mm DIAMETER BUNDI TUBE
GA23697A
GA23697A
GA23697A
88
1
10mm DIAMETER BUNDI TUBE
GA23697B
GA23697B
GA23697B
