Operating Instructions For TD/TAD4 Dual Fuel Burner
June 13 96 of 165 TD/TAD4 Manual Rev 4
ITEM
QTY.
DESCRIPTION
DWG/PART No.
1
1
TD410 LOW NOx COMBUSTION HEAD ASSEMBLY
TD410 COMBUSTION HEAD ASSEMBLY
GA23554
GA23556
2
1
T4 VANE CASTING
GA08715
3
1
T410 FAN IMPELLOR (WHITE)
T415 FAN IMPELLOR (BLUE)
T420 FAN IMPELLOR (BLACK
GA8765
GA8764
GA8763
4
1
T4 BODY (FAN HALF)
GA08716
5
1
EYEBOLT T4 16MM 58mm O/D x32mm I/D
EYEBLT00100
7
1
TD410 7.5KW FAN MOTOR
MOTORF01210
8
1
ANODISE OUTER SHUTTER TD410, TD415
GA15127
9
1
ANODISE INNER SHUTTER TD410, TD415
GA15125
10A
1
SILENCER FOR TD410, TD415
GA08891
GA08893
10B
1
T410/415 SNORKEL SILENCER WITH CHAMFERED CORNERS
GA21875
10C
1
SNORKEL SILENCER MESH
GA16838
11
4
SPACER FOR MOD PLATE
GA07961
12
2
ROD END BEARING
BEAROS00250
13
1
SERVO MOTOR LINKARM
GA18765
14
1
MOD PLATE
GA17188
15
1
ETC6027 CANBUS SERVO MOTOR 12Nm
ETCRAT00745
16
1
T6 CONTROL PANEL MOUNTING BRACKET
GA9093
17
1
542 ELECTRICAL ENCLOSURE
552 ELECTRICAL ENCLOSURE
667 ELECTRICAL ENCLOSURE
GA10724
GA10720
GA12409
18
1
DOOR FOR 542 ELECTRICAL ENCLOSURE
DOOR FOR 552 ELECTRICAL ENCLOSURE
DOOR FOR 667 ELECTRICAL ENCLOSURE
GA10726
GA10722
GA10723
19
1
SIDE ENTRY GASKET
GA08990
20
1
GAS TRAIN FLANGE 80
GA07099
21
-
-
-
22
1
T4 VGD40 SIDE ENTRY ASSEMBLY DN65
T4 VGD40 SIDE ENTRY ASSEMBLY DN80
T4 VGD40 SIDE ENTRY ASSEMBLY DN100
GA23524A
GA23524B
GA23524C
23
1
MALE STUD COUPLING 10MM x 1/4" BSP
COMPAD00485
24
1
10mm BUNDI TUBE
BUNDIT00145
25
1
PRESSURE SWITCH
PRESWI00246
